DV SD-1501
Core drill on rail - wet - 3 gears
Wet
TALPA + DA VINCI technology - electric air-cooled 1P motor + CARDI adv. electronics
Ultra heavy-duty, powerful, for small-mid drillings
20-102 / 3/4"-4" [mm]/[in]
2500/2200 W
Main features
Drilling mode Wet
Technology TALPA + DA VINCI technology - electric air-cooled 1P motor + CARDI adv. electronics
Drilling diameter - masonry 20-102 / 3/4"-4" [mm]/[in]
Drilling diameter - reinforced concrete 20-102 / 3/4"-4" [mm]/[in]
Input power (max / rated) 2500/2200 W
Input current (max / rated) 11.5/10 A
Material Reinforced concrete, Concrete / stones / asphalt, Masonry / bricks
Main track length 1500/59" [mm]/[in]
Usable stitch drilling length 500/19"3/4 [mm]/[in]
Users
- Company specialized in material's testing
- Construction company / general contractor
- Professional drilling and cutting company
- Demolition expert
Applications
- Sampling of cores
- Stitch drilling
- Opening of doors / windows / skylights
Included items
Core drill motor: T1 200-EL-41
Rail: DV SD-1500
Accessory: 501163 – Spanner 19 mm
Accessory: 505284 – Allen key 6 mm
Accessory: 505039 – Rapid-lock plate for core drill motor to L 180 / L 200 / L 300 stands
Technical features
Operational mode On rail
Drilling mode Wet
Technology TALPA + DA VINCI technology - electric air-cooled 1P motor + CARDI adv. electronics
Drilling diameter - masonry 20-102 / 3/4"-4" [mm]/[in]
Drilling diameter - reinforced concrete 20-102 / 3/4"-4" [mm]/[in]
Input power (max / rated) 2500/2200 W
Input current (max / rated) 11.5/10 A
Material Reinforced concrete, Concrete / stones / asphalt, Masonry / bricks
Motor type | Rated voltage - rated frequency Electric - 1P | 230 V - 50-60 Hz
Gears 3
Rated no-load rpm 540/1290/1800 RPM
Rated load rpm 380/920/1280 RPM
Core bit connection 1"1/4 UNC + 1/2G
PRCD / GFI Included
Noise emission value - A-weighted sound pressure level (LpA) 90 [dB (A)]
Noise emission value - A-weighted sound power level (LWA) 103 [dB (A)]
Main track length 1500/59" [mm]/[in]
Usable stitch drilling length 500/19"3/4 [mm]/[in]
Weight 34.75/76.6 [kg]/[lb]
Dimensions - L x W x H 1580x460x1200 - 62"x17"3/4x47"1/4 [mm]/[in]
Supplied in Carton box
